Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: SBJX
  • Model Number: SBJX-T20
  • After-sales Service Provided: Overseas service center available
  • Type: TDC Flange Forming Machine

Packaging & Delivery

Packaging Details Exported Standard Packing--wooden for TDC Flange Forming Machine
Delivery Time Within 20 working days

Specifications

TDC Flange Forming Machine
1.SJBX-T20
2. ISO9001
3. CE

TDC unit is one of the two universal flange making systems in the world. It can save time and material drastically with its wel-seal, strong and durable joint structure. So it is specially suitable for producing a duct with a large sectional area.



Technical date



Type

Edge wide

Capacity

Motor

Weight

Dimension

20A

88mm

0.8mm

3kw

2000kg

2800×600×1150mm

30A

120mm

1.0mm

3kw

2200kg

3000×600×1150mm

35A

131mm

1.0mm

3kw

3000kg

3200×600×1200mm

40A

141mm

1.2mm

4kw

3000kg

3200×600×1200mm



Type

Edge wide

Capacity

Motor

Weight

Dimension

20B

86.5mm

0.8mm

3kw

2000kg

2800×600×1150mm

30B

118mm

1.0mm

3kw

2200kg

3000×600×1150mm

40B

176mm

1.2mm

4kw

3000kg

3200×600×1200mm



Type

Name

Capacity

Size

T-20DC

Duct comer

2.5mm

a=95mm

T-30DC

Duct comer

3mm

a=105mm

T-40DC

Duct comer

3.5mm

a=123mm

LT-30

Duct comer

3mm

a=105mm

T-35DC

Duct comer

3mm

a=106mm

BC-10

Duct clip

5mm







Application in duct making

1, Grooving

2, TDF Flange

3, "C”Locking Seam

4, Single and Double

 hem locknection

5, TDC flang

6, Clip

7, Pittsburgh Lock

Single lock

8, Snap lock

9, Elbow Lock

10,"S" Locking seam

11,TDC corner

12,Corner conneting



How to get a accurate quotation from us?

provide us the detail of the material such as metal thickness and width,cutting area

 How to check imported charges or tax ?

Call your Customer.tell them machine HS code.

Spiral duct forming machine is 8455229090

 rolling machines are 84622990. shearing machine is 84623990.rolling machine is 8455229090,seam welding hs code is 85152900

  Payment terms,MOQ,warranty,FOB...

payment terms 30% down payment with order by T/T,the balance of 70% to be paid on delivery to the port .

minimum order quantity:1 set,FOB Shanghai.

delivery time :20days after receipt of formal order and 30% deposit.

warranty:12 months following delivery. We offer online service 24 hours all day long, Skype, Email etc .You can contact us any time,if urgently,please call us.

 whats policy for guarantee and broken parts?

Warranty period of equipment lasts a year, during which the broken parts and spares caused by quality can be offered free.
